Modern Flames Orion V2 Traditional Built-In Series

$2,499.00 USD

Sale Sold out

Shipping calculated at checkout.

The Modern Flames Orion V2 Traditional Built-In Series brings next-generation virtual flame technology to a classic firebox shape. It can slide into many existing wood or gas fireplace openings as a retrofit, or install as a built-in clean-face or self-trimming fireplace in new construction, pairing 24 LCD flame options with a lit split-wood log set, built-in speakers, and the Modern Flames+ app.

This series suits homeowners replacing a dated masonry or prefab fireplace with realistic, vent-free electric, and new builds that want a traditional hearth look without gas. Modern Flames rates the Orion V2 Traditional for indoor and covered outdoor use.

At a Glance

Best for	Converting existing wood or gas fireplaces, traditional living rooms, and new builds that want a classic hearth
Installation	Retrofit into an existing fireplace, built-in clean face, or self-trimming
Available sizes	26", 30", 36", 42", and 54"
Flame display	Next-generation LCD with adaptive brightness and 24 built-in flame options
Heat output	26" and 30": 5,000 BTU (approx. 400 sq ft). 36" to 54": 5,000–8,500 BTU (approx. 400–700 sq ft)
Power	120V plug included, hardwire ready; 36" to 54" also support 240V
Audio	Built-in speakers, Bluetooth streaming, and three crackling soundscapes
Controls	Remote, Modern Flames+ app, and compatible smart-home systems
Warranty	5-year warranty

Good Fit If

You want to convert an existing wood-burning or gas fireplace to electric.
You prefer a classic, taller firebox shape to a wide linear look.
You want the realism of a lit log set and deep, multi-dimensional flames.
You want the option to plug in rather than hardwire.
You like the idea of a fireplace that gains new flame styles and themes over time through app updates.

Not Ideal If

You want a wide, modern linear fireplace. See the Orion V2 Multi or Orion V2 Slim.
You want a corner or three-sided installation.
Your existing fireplace opening is too shallow for the roughly 10-inch-deep firebox.
Your outdoor space has no solid roof overhead. Outdoor approval depends on a qualifying patio cover.
You need the fireplace to act as the primary heat source for your home.

Key Features

Next-generation LCD flame display: Sharper contrast, deeper blacks, and richer color, with adaptive brightness that balances the flames to the room's light.
24 flame options out of the box: Three flagship multi-dimensional flame styles designed specifically for the Traditional firebox, plus a fourth slot for additional flame styles, colors, or themes from the app library.
Over-the-air updates: New flames and themes arrive through the Modern Flames+ app, and up to six experiences can be stored on the fireplace at once.
Lit split-wood log set: Internally lit logs made from real split wood sit over an active glowing ember bed, highlighted by brighter downlighting.
Premium audio: Custom speakers, Bluetooth streaming, and three crackling soundscapes: Classic Crackling, Starry Night, and Stormy Night.
PTC ceramic heater: Quiet, consistent supplemental heat, with dual-voltage 240V capability on the 36", 42", and 54" models for higher output.
Three installation methods: Retrofit into an existing fireplace, build in with a clean face, or finish as a self-trimming unit.
Smart control: Adjust flame, ember-bed, and downlight colors from the remote or the iOS/Android app, and connect to compatible smart-home systems.

Installation and Fit

For a retrofit, the Orion V2 Traditional slides into an existing fireplace opening. Optional Modern Flames surround trim kits are offered for the 26", 30", and 36" models to cover a wider opening. In new construction, it can be framed as a built-in clean-face fireplace or finished as a self-trimming unit.

Built-in clean face requires a 10-1/2" minimum rough-opening depth; self-trimming requires a 10" minimum.
Rough openings range from 23" W x 18-3/4" H on the 26" model to 50-15/16" W x 32-3/4" H on the 54" model.
All sizes include a 120V plug and are hardwire ready. The 36", 42", and 54" models can be wired for 240V to increase heat output.

Outdoor installation

The Orion V2 Traditional can go into an outdoor kitchen or covered patio wall, provided it is built in and protected by a solid roof that keeps rain and direct sunlight off the glass. Modern Flames sets minimum distances for how far that cover must extend in front of and beside the fireplace, plus a minimum height for the unit above the patio floor, so check those figures in the manual before framing. Open decks and slatted pergolas don't provide enough protection.

Before ordering, measure your existing opening (width, height, and depth) or confirm your framing plan against the model-specific manual.

What’s Included

Modern Flames Orion V2 Traditional electric fireplace
Lit split-wood log set and ember bed
Remote control
Built-in WiFi for the Modern Flames+ app
Manual and specification documentation

Surround trim kits for retrofit installations are sold separately.

Product Specifications

Brand	Modern Flames
Series	Orion V2 Traditional
Product category	Traditional virtual (LCD) built-in / insert electric fireplace
Installation options	Retrofit, built-in clean face, self-trimming
Unit depth	9-7/8"
Heat output	5,000 BTU (26", 30"); 5,000–8,500 BTU (36", 42", 54")
Power	120V plug included, hardwire ready; 120V/240V dual on 36" and up
Flame options	24 included, expandable through the Modern Flames+ app
Audio	Custom speakers, Bluetooth, three soundscapes
Location rating	Indoor; outdoor as a built-in under a qualifying patio cover
Warranty	5 years

Size	Model	Overall W x H	Rough opening W x H
26"	OR26-TRAD-V2	25" x 19-5/8"	23" x 18-3/4"
30"	OR30-TRAD-V2	30-1/2" x 19-5/8"	28-1/4" x 18-3/4"
36"	OR36-TRAD-V2	35" x 24-13/16"	32-5/8" x 23-7/8"
42"	OR42-TRAD-V2	41" x 27-13/16"	38-3/4" x 26-3/4"
54"	OR54-TRAD-V2	53-3/8" x 33-13/16"	50-15/16" x 32-3/4"

Common Questions

Will the Orion V2 Traditional fit my existing fireplace?

Many existing wood and gas fireplaces can accept it. Measure the opening width, height, and depth and compare them with the rough-opening dimensions for each size. Optional surround trim kits for the 26-, 30-, and 36-inch models help cover wider openings.

How is the Orion V2 Traditional different from the original Orion Traditional?

V2 upgrades the LCD panel and adds adaptive brightness, expands to 24 flame options with new styles delivered through the Modern Flames+ app, adds built-in speakers with Bluetooth, introduces a lit split-wood log set, and is approved for covered outdoor built-in installations.

Does it plug in or need to be hardwired?

Every size includes a 120V plug and is also hardwire ready. The 36-, 42-, and 54-inch models can be wired for 240V to unlock higher heat output.

Can the flames run without heat?

Yes. The flame display, lighting, and audio can all be used with the heater off, so the fireplace can be enjoyed year-round.

Can the Orion V2 Traditional be installed outdoors?

Yes, when it is built in under a solid patio roof that shields it from rain and direct sun. The manual lists minimum cover distances in front and to the sides, along with a minimum height above the floor. Open decks and slatted pergolas are not approved locations.

Which size should I choose?

For a retrofit, choose the largest size that fits your existing opening. For new construction, the 26- and 30-inch models suit bedrooms and smaller rooms, while the 36-, 42-, and 54-inch models suit living rooms and great rooms.

Guides and Manuals

Specifications and installation guidance on this page are based on current Modern Flames manuals, specification sheets, and product documentation linked below. Confirm final framing and electrical requirements in the model-specific manual.
