40″ wide and 12″ deep electric fireplace – The Panorama Series of built-in electric fireplaces have been designed to give you the maximum in flexibility in selecting a unit that perfectly suits your needs.
The stylish new BI-40-DEEP electric fireplace will be a focal point in any space – indoor or outdoor.
Panorama fireplaces are rated for Indoor or Outdoor use.
Full Frame Viewing Area
The Panorama Series give you multiple lengths and depth options as well as giving you the ability to install your fireplace with your choice of finishing material built right to the glass for a “clean face” design or using the provided black metal surround. Your choice – your design!
A Kaleidoscope of color
Featuring the vibrant Fire & Ice® flame set, with just a click of your remote you can easily change the flame color from blue to purple to violet to orange or yellow.
Note: Deep models come with large glass nuggets, diamonds fire glass media, and an 11 piece log set.
Features
- All models are rated for either indoor or outdoor use
- Cover MUST be purchased if installing outdoors
- FIRE & ICE ® Flame presentation ‐ three light strips allow for yellow, orange, blue, violet, and rose-colored flames
- Ambient Canopy lighting in 13 colors
- DEEP models have 2 flame sets
- Can produce up to 4800 BTU of heat, enough to heat up to 500 sq feet
- 2 Stage heater
- Hard‐wire ready
- Thermostat‐hard wire ready
- Flame can operate without heat
- Single remote control for flame, ambient canopy lighting & heater included
- Full frame viewing ‐ unit allows for your choice of finishing material to come right to the glass
- Optional black steel surround comes in the box – it is up to you if you want to use it or not.
Specs
BI-40-DEEP | |
Volts | 120 |
Amps | 12.5 |
Watts | 1500 max |
Heater | 1500 watts high 750 watts low |
No Heater | 22 watts |
Lamps | LED 22 watts |
Rotor Motor | 1 at 5 watts |
Height, Width, Depth | 23 5/8 x 38 1/8 x 12“ |
Glass View Opening | 11 7/8 x 34 1/4” |
Surround Size | 15 7/8 x 38 1/8” |
Shipping Size | 25 5/8 x 46 1/4 x 15 1/4” |
Shipping Weight | 100.5 lbs. Glass Included |
Plug Location | Left Side |
Cord Length | 76” |
Approx. Heating Area | 400 sq. ft. |
Installation
- Brochure
- Specs
- Manual
- Feature Sheet
- Installation Instructions
- Outdoor Installation Instructions
- Replacement Glass Measurements
- Panorama Size Comparison
- Panorama Safe Drill Zone
INCLUDED ACCESSORIES
The BI-40-DEEP comes standard with our ICE media set, an 11 piece log set, as well as a black steel surround and a remote.
